Basic Air Suspension Kit for MAN TGE FWD / RWD 2017-2022 - 4.0 TON Airbags

In stock - 10 items available
Regular price £279.00 inc. VAT
Drivetrain
Compressor

Semi Air Suspension Kit Designed for:

  • MAN TGE 2017-2023
Make/Model MAN TGE
Year 2017-2023
Drivetrain Choose Drivetrain in the options.
Rear Wheel Layout Single Rear Wheel
Body Type Panel Van, Tipper, Motorhome, Camper, box van, horsebox, luton, crew van, recovery, dropside, flatbed
Chassis Type All standard type chassis



EXCLUDING AL-KO TYPE TORSION BARS CHASSIS

MIN (0.7 BAR )WHEN UNLOADED AND  ( 6 BAR )WHEN LOADED

HEIGHT: MIN 90MM, MAX 200MM. ( MAX HEIGHT IS DEPENDS ON WEIGHT OF LOAD )

All electrical components/gauges/valves are only to be used in the INTERIOR.

Rubena branded air bags support up to 4000 KG per pair

Martech branded air bags support up to 5000 KG per pair

WEIGHT UPRATING ONLY APPLIES TO LEISURE VEHICLES. WILL NOT WORK FOR COMMERCIAL VEHICLES.
